Push plunger type(Z7-110)

Z7-110 Featrues Adopt outer shell with intensive plastic and sealed construction,better mechanical strength and water-proof and oil-proof Side fixed form and swift contact Variety of levers Specification Item Data Rating load 10A/250VAC Operation speed 0.1mm-50cm/s Operation frequency Mechanical 240time/min Electrical 20time/min Insulation resistance 100MO(above)(DC500V) Contact resistance 25MOInitial value Withstand voltage Non-connection wire 1000VAC Every terminal 1500VAC Vibration Misoperation 10-55Hz (Amplitude)1.5mm Impact Durable 1000m/s Misoperation 300m/s Life Electical 100,00(above) Mechanical 1,000,000(baove) Protection degree IP65 Ambient operating temperature -25-80? Humidity <85% ?????????
