DC Solid state relay(Dual lnline type)(SSR-DA1101)

SSR-DA1101 control voltage 4-12VDC control current 6-25mA reverse voltage 32VDC guarantee close voltage 1VDC guarantee open voltage 3VDC load voltage 75-480VAC load max current 300-400A load minni current 0.05A breakover voltage =1.5VAC output leakage current =8mA medium withstand voltage =2000VAC insulating resistance =100MO switching time =1mS frequency range 50-60hZ operating temperature -20-70? load current safety factor (resistive load)50-60% (inductive load)30-40%
