Microcontroller based.
Current actuation threshold adjustable
Trip and start-up delay adjustable
Possible to use for scanning of current from current transformer
up to 600A
1C/O output-8A
LED indication for power supply and relay status
1 module Din-rail mounting
Cucurrent monitoring relays are designed to protect motors and systems against under or over current fault in the case of the value of current above the set threshold values.
